40G QSFP+ to 8x LC connector Breakout Active Optical Cable
Name:

40G QSFP+ to 8x LC connector Breakout Active Optical Cable

Class:
Active Optical Cable (AOC)
Type:
40G QSFP+ to 8x LC connector Breakout Active Optical Cable

40G QSFP+ to 8x LC connector Breakout Active Optical Cable Specification


Fiberer Rohs

Description

Fiberer QSFP+ to 8 x LC Connector Breakout Optical Cable are a high performance, low power consumption, long reach interconnect solution supporting 40G Ethernet, fiber channel and PCIe. It is compliant with the QSFP MSA and IEEE P802.3ba 40GBASE-SR4. Fiberer QSFP+ Breakout Cable is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s. QSFP+ Breakout Cable are suitable for short distances and offer a highly cost-effective way to connect within racks and across adjacent racks. These breakout cables connect to a 40G QSFP+ port of a switch on one end and to four 10G SFP+ Transceivers of a switch on the other end.




Features

 Full duplex 4 channel 850nm parallel active optical cable

 Transmission data rate up to 10.3Gbit/s per channel

 SFF-8436 QSFP+ compliant

 Hot pluggable electrical interface

 Differential AC-coupled high speed data interface

 4 channels 850nm VCSEL array

 4 channels PIN photo detector array

 Maximum link length of 300m on OM3 Multimode Fiber (MMF)and 400m on OM4 MMF

 Low power consumption

 Housing isolated from connector ground

 Operating case temperature 0°C to +70°C

 3.3V power supply voltage

 RoHS 6 compliant




Applications

 Infiniband transmission at 4ch SDR, DDR and QDR

 40GBASE-SR4 40G Ethernet

 Data Center





Packaging & Labeling
To protect each of product, Fiberer will use firm and secure Package, and common use Fiberer Label if customer not remark.
It is available to use custmized labeling and packaging for customer request.

Shipment
All shipment will be succssful to arrive customer's address. Fiberer try our best to let the shipment fast for customers, and the common express is by air of Fedex, DHL, UPS, EMS and TNT.
If the customer pay Fiberer the shipment charge, it will use Fiberer express account for the shipment, otherwise it need to use the customer's express account.

Customized & OEM
Fiberer always do Customized for customer's request successfully, It is available for Customized & OEM.
